-Monitor your vehicle or asset’s location in real-time with pinpoint accuracy.

-Stay connected with fast, reliable 4G and 2G network compatibility.

-Enjoy up to 180 days of standby time on a single charge.

-Set virtual boundaries and receive instant alerts for unauthorized movements.

-Built to withstand harsh environments with an IP67 waterproof rating.

-Low power consumption for extended use.



GNSS Specifications

• Positioning System: GPS + BDS + LBS

• Positioning Accuracy: <2.5m CEP

• Tracking Sensitivity: -165dBm

• Acquisition Sensitivity: -148dBm

• Time to First Fix (TTFF):
  Hot Start: ≤2 seconds (average)
  Cold Start: ≤38 seconds (average)



Cellular Specifications

• Communication Network: GSM

• Frequency: Quad-band 850/900/1800/1900 MHz



Power Specifications

• Battery: 270mAh/3.7V industrial-grade Li-Polymer battery

• Input Voltage: 9-90VDC



Interface Specifications

• LED Indication:
  GNSS (Blue)
  Cellular (Green)
  Power (Red)

• SIM Card: Standard-SIM

• Data Storage: 32+32Mb



Physical Specifications

• Dimensions: 78.0 x 41.0 x 13.0mm

• Weight: 41g



Operating Environment

• Operating Temperature: -20°C to 70°C

• IP Rating: IP65



Additional Features

• Sensors: Accelerometer

• Ignition Detection: ACC detection
• Scenarios Supported:
  Vehicle movement alert
  Over-speed alert
  Geo-fence
  Vehicle battery detection
  Power supply disconnection
